DESCRIPTION

Basic Info

Model NO.	CODEJET
Application of Classification	Ink Jet Printer
Working Patterns	On-Line
Supplies	Ink
Packaging	Box
Plate Type	Thermal Inkjet Printer
Print Color	Single Color
Voltage	AC 220V
Dimensions(L*W*H)	186.5X34.5X126 mm
Weight	3 Kg
Print Dimension	12.7 mm-304.8 mm
Ink Type	Water/Solvent Based
Key Selling Points	Long Service Life
Print Height	12.7 mm, 25.4 mm, 38.1 mm, 50.8 mm and More
Print Speed&Resolution	100m/Min& 600*300 Dpi, 180m/Min& 300*150 Dpi
Interface Type	USB/Sensor/Encoder/Warning Light/LAN/Io
Print Resolution	150-600 Dpi
Operation	External Computer
Temperature/Humidity	5centigrade~35centigrade / 10%~90%
Max Power	120W
Transport Package	Carton Box
Specification	257*38mm
Trademark	Dikai
Origin	Shanghai
HS Code	8456110090
Production Capacity	500

Product Description

Thermal Inkjet Printer-Codejet

DK CODEJET printer support cascading of max 6 sets of CODEJET, one set CODEJET can control 4 print heads. Therefore, CODEJET can have up to 24 print heads, which can satisfy most of user's requires. Operating the software on computer is more convenient and simple, it also means that there is no limit for the language of print content. CODEJET is a powerful inkjet printer, the high speed mode can reach 200m/min on industrial printing system. CODEJET printer is able to connect other equipments through computer, PLC or central controller, which is suitable for automatic production system. Also, CODEJET support real time control and real time data. CODEJET appeared on market for more than 8 years. After several revisions, there are lots of common functions and especial functions for specialized market.

Features▪ Software control, massive data storage▪ Communication support▪ Max 24 printheads connection▪ Print real-time data▪ Customize special application▪ HPTIJ2.5 TIJ Ink Controller Print Head

Product Parameters

Specification
Print Tech	HP TIJ2.5
Print Height	Max 304.8 mm
Head Quantity Supported	24 heads (Note: One Codejet Printer can only support 4 print heads, but can connect with another 5 Codejet printers to support up to 24 print heads. And CODEJET print heads only can use on CODEJET controller)
Print Resolution	150-600 DPI
Print Speed	200 m/min
Ink Type	Water/Solvent based
Ink Supply	42ml Ink cartridge. 42ml+370ml Ink bag and 500ml bulk ink supply is optional.
Interface	USB/Sensor/Encoder/Warning Light/LAN/IO
Sensor	Simulation sensor/ External sensor
Accessories (include)	CODEJET controller, print head, PC software, USB, Sensor, Connection cable
Accessories (optional)	Encoder, warning light
Barcode type	EAN8\EAN13\EAN128\CODE25\CODE39\CODE128\UPC12\ UPC-E\ITF-14\ PDF417\QRCODE\MAXICODE\DATAMATRIX
Power	110-220VAC 50/60Hz
Max power	120W

Printing Sample

Company Profile

Founded in 1995, Shanghai DiKai Coding Industry Co. Ltd is specialized in manufacture, development, distribution and service of industrial coding machine together with its consumables. Our products widely meet kinds of coding requirements coming from the fields of food, pharmacy, cosmetic, etc.

We have been a leader in the China domestic in the field of coding currently, with 12 offices around China. Currently, we have been a leader in the field and have now brought our expertise to the international market.

With the rich experience, in-depth engineering skill and production capacity, we will supply goods that are perfectly suited for the destination market.

With the belief of "Reliable Quality, Perfect Services, Competitive Prices" and most importantly "High Credit", we are committed to working alongside our customers.

With a system in place to cover all aspects of the order from the initial inquiry to the final delivery, we will ensure all customers to receive the best service possible.

All at the company are ready to begin collaboration and look forward to doing business with your company. We invite you to browse through the products displayed here and on our website, or to contact us directly. We are certain that this will not be a move you′ll regret.

FAQ

1. Why choose Dikai?

-- Our company has dedicated to development, manufacturing and sales of qualified coding machines and consumables for 25 years. Meanwhile, we commit ourselves to satisfy every customer's different needs in coding and marking area. 2. What's the regular lead time for Dikai Products?-- Lead time for all Dikai good is 1-2 weeks after order confirmation. For the stocked goods, delivery can be made in 2 working days.3. What's the warranty of Dikai goods?-- Regularly 12 months after leaving Dikai Warehouse.4. How about your after-sales service?-- For the countries where we have distributors, we depend on our distributor to do after sales services. Dikai also provide online technical services besides of continuously upgraded video supports.GO HOME TO SEE MORE
