Adhesive Printing Machine Environmental Bag Screen Printing Machine Manual Flat Silk Screen Printers Printing Machine

Products

Adhesive Printing Machine Environmental Bag Screen Printing Machine Manual Flat Silk Screen Printers Printing Machine

Adhesive Printing Machine Environmental Bag Screen Printing Machine Manual Flat Silk Screen Printers Printing Machine

Characteritics: 1. Four cylinders motorized to achieve even pressure with clear mesh2. Decelerator driving printer head

Send your inquiry

DESCRIPTION

Basic Info
Model NO. RYBL-200100P
Application Paper Printing
Print Interface USB2.0
System Supported Windowsxp32
Pringting Thickness 0-40mm
Height of Instart off-Screen 0-30mm
Transport Package Carton
Specification 2600*2400*1350
Trademark ROYAL PACKING
Origin China
Product Description
Characteritics:
1. Four cylinders motorized to achieve even pressure with clear mesh2. Decelerator driving printer head moves up and down, speedy and stable 3. With four-pillar up and down movements, speedy and stable 4. High-precision guide track with "MEGADYNE" belt, dual-band drive, high printing precision 5. Oil-water separator link to cylinder to ensure even and stable movement away from screen 6. Microcomputer with fault display function for maintenance

1. Features
The structure of this machine is a complete screen printing machine. The operation principle is the four-column overall screen lifting, the platform walks in and out automatically, and the one-button automatic program coherent action is completed. Suitable for large advertising printing, acrylic, film, glass, silicone, etc.

2. Features and functions:
1. Operation function: PLC programming system, touch screen operation.2. Lifting method: The overall lifting height of the four columns is 250mm, and the power is the frequency conversion control motor RV reducer.3. Running platform power: Servo electric push rod is used to stop with high precision.4. Printing platform: Vacuum adsorption platform, using high-pressure blower, solenoid valve to control automatic vacuum and firm adsorption of printed matter.5. Printing power: The gear motor frequency conversion controls the printing and ink return to run back and forth, and the printing speed and stroke length can be adjusted by the proximity switch induction control.6. Girder structure: Double linear guide rail sliders are used to fix the printing head to slide, and it runs smoothly at high speed.7. Squeegee and ink knife: Pneumatically switch the action of the two knives, and use SDA self-locking four cylinders to adjust the pressure, easy to operate.8. Screen frame device: Pneumatic splint, movable clamping, fine-tuning handles for front, rear, left, and right, convenient and accurate plate alignment.9. The configuration of this machine may be customized according to the actual requirements of customers, and the pictures of the machine are for reference only




Main Technical Specifications
ITEMRYBL-15080RYBL-17090
Max. Printing Size1500 x 800mm 1700 x 900mm
Printing Table Size1700 x 900mm1900 x 1000mm
Max. Screen Frame Size1800 x 1000mm2000 x 1100mm
Pringting Thickness0-40mm0-40mm
Height of instart Off-screen0-30mm0-30mm
Max. Printing Speed600t/h600t/h
Weight1200kg1500kg
Overall Dimension2400 x 1280 x 1750mm2650 x 1380 x 1750mm
Printing Motor0.4kw0.4kw
Lifting Motor2.2kw2.2kw
Fans1.5kw1.5kw
Power3P4N 50Hz 380v4.1kw3P4N 50Hz 380v4.1kw
ITEMRYBL-18090RYBL-23090
Max. Printing Size1800 x 900mm 2300 x 900mm
Printing Table Size2000 x 1000mm2700 x 1000mm
Max. Screen Frame Size2200 x 1200mm2600 x 1000mm
Pringting Thickness0-40mm0-40mm
Height of instart Off-screen0-30mm0-30mm
Max. Printing Speed600t/h600t/h
Weight1650kg1800kg
Overall Dimension2750 x 1380 x 1750mm3100 x 1380 x 1750mm
Printing Motor0.4kw0.4kw
Lifting Motor2.2kw2.2kw
Fans1.5kw1.5kw
Power3P4N 50Hz 380v4.1kw3P4N 50Hz 380v4.1kw
